Custom Nanoimprint Lithography Solutions

---

• Capabilities: UV-NIL, thermal NIL, SmartNIL® technology (fully automated high-resolution patterning)

• Key Features:

• Sub-20nm resolution with low-defect imprinting

• Fully automated alignment with sub-100nm overlay precision

• Compatible with 4", 6", and 8" wafers

• Integrated UV curing and temperature control

• Use Cases: High-fidelity pattern transfer for optics, metasurfaces, and photonics

• Capabilities: Thermal NIL with high pressure and temperature uniformity

• Key Features:

• High aspect ratio imprinting for 3D structures

• Supports wafer sizes up to 6"

• Step-and-repeat or full-wafer imprint modes

• Air cushion press for bubble-free imprints

• Use Cases: Master mold replication, pattern transfer on thermoplastics, R&D tooling

• Resist Coating Capabilities:

• Uniform spin-coating down to 50 nm film thickness

• Substrate size support: pieces up to 6" wafers

• UV Curing:

• High-intensity collimated UV light for rapid resist curing

• Wavelengths: 365 nm and 405 nm options

• Use Cases: Photoresist deposition, imprint resist curing, custom resist trials

• Bruker Dimension Icon AFM: High-resolution 3D surface imaging (sub-nm vertical resolution)

• Thermo Fisher SEM (Helios Series): Cross-section and surface imaging of nanoimprint features

• Zygo Optical Profilometer: Non-contact step height and roughness analysis

• Ellipsometry (J.A. Woollam): Thin film thickness and optical constant extraction

Quick-turn projects to demonstrate NIL performance for your specific use case.

• What’s included:

  • Custom process design (UV or thermal NIL)

  • Imprint trials on customer or standard substrates

  • Basic pattern metrology (SEM, profilometry, AFM)

• Typical duration: 4–8 weeks

• Ideal for: Universities, startups, product development teams validating NIL viability

Applied development tailored to client applications with structured milestones and regular deliverables.

• Focus Areas:

  • Pattern replication and resist/material compatibility

  • Mold optimization and surface treatment

  • Process tuning for specific device stacks

• Deliverables: Data reports, imprinted substrates, transferable process recipes

• Duration: 1–6 months

Short-run nanoimprint manufacturing for pre-production or demonstration purposes.

• Capabilities:

  • Up to 100 wafers/month (4”–6”)

  • Flexible substrate support (glass, Si, PET, etc.)

  • Integrated resist coating and curing

• Applications: Optics, sensors, display films, photonic surfaces


We selectively engage in co-development projects with partners aligned on long-term NIL innovation.

• Structure:

  • Joint roadmap definition

  • Shared access to tools and technical IP

  • Option for exclusive technology licenses

• Limited availability: Based on strategic fit and bandwidth
